Opis
Product type: Bulk Cable
Type: DMX & AES/EBU Cable, Installation Cable
Color: grey
Overall diameter: 5 mm
AWG: 24
Center conductor cross section: 0.22 mm²
Center conductor material: OFC
Center conductor construction: 7 x 0.20 mm
Number of internal conductors: 2
Shield material: Copper galvanized
Shield: woven
Line surge impedance: 120 Ohm(s)
Line resistance: < 85 Ohm(s)
Capacitance: 45 pF/m
Temperature range: -40 – 105 °C
Weight: 0,04575 kg
