System specifications:
Peak power handling: 120 W
Program power handling: 60 W
RMS/AES power handling: 30 W
Speaker type: 2-way coaxial
Drivers: 4”
Impedance: 16 Ω
Line Transformer Tappings:
1: 208 Ω – 100 V / Not used – 70 V / 24 W
2: 417 Ω – 100 V / 24 W – 70 V / 12 W
3: 833 Ω – 100 V / 12 W – 70 V / 6 W
4: 1667 Ω – 100 V / 6 W – 70 V / 3 W
Dispersion: Conical 165° (average 500 Hz to 5 kHz @ -6 dB)
Connectors: 4-pin Euro Terminal Block
Sensitivity (1W/1m): 80 dB
Sound Pressure (Max. W/1m) @ 16 Ω: 95.1 dB
Frequency range (-10 dB): 65 Hz – 20 kHz
Frequency response (± 3 dB): 85 Hz – 20 kHz
Product Features:
Dimensions: 170 x 223 mm (Ø x H)
Connection cable length: 3.5 m
Construction: Polypropylene
Front finish: Aluminium grill
Mounting & handling: Dual snap hook and dual Gripple™ hanger
Accessories: Included: Connection cable with dual steel core, snap hook & open ends – 3.5 meter, 2 Gripple™ hangers
Weight: 2.23 kg
