Audac CEP803

Opis

RMS/AES power handling
@ 4 Ω: 8 x 30 W
@ 70 V: 8 x 30 W
@ 100 V: 8 x 30 W
Signal / Noise: > 100 dB
THD+N (@ 1 kHz): < 0.05% (1/8 rated Power)
Crosstalk (@ 1 kHz): < 70 dB
Frequency Response (± 3 dB): 110 Hz – 20 kHz
Technology: Class-D
Protection: DC Short circuit, Over heating, Over load, Signal limiting
Cooling: Convection cooled
Operating temperature: 0° ~ 40° @ 95% Humidity
Power:
Supply: Switching mode
Source: 100 ~ 240 V AC / 50 ~ 60 Hz
Consumption: Standby 0.6 W
Idle: 17.5 W
Nominal (1/3 MUP): 150 W
Nominal (1/8 MUP): 68 W
Inputs:
Connector: IEC C14 Connector, Input linking through miniature switches
Connector: 3-pin Euro Terminal Block (Pitch – 3.81 mm)
Outputs: Connector: 4-pin Euro Terminal Block (Pitch – 5.08 mm)
Inputs: Sensitivity: -0.5 dB ~ 10.5 dB
Outputs:
Voltage / Impedance: 4 Ω, 70 V / 167 Ω, 100 V / 333 Ω

Product Features:
Mounting: 19”
Unit height: 1 HE
Colours: Black
Dimensions: 482 x 44 x 335 mm (W x H x D)
Weight: 6 kg
Construction: Steel
