Opis
SYSTEM SPECIFICATIONS:
Max. Power: 60 W
RMS Power: 30 W
Sensitivity (1W/1m): 88 dB
Speaker type: 2-way coaxial
Impedance: 8 ohm
Connectors: Multi-tap Fast-con™ connections
Sound Pressure (Max. W/1m) @ 100 V: 103 dB
Frequency Response (± 3 dB): 55 Hz – 20 kHz
Range (-10 dB): 45 Hz – 20 kHz
Dispersion Conical: 150°
Drivers: LF 6.5″ Woofer, HF 1″
Line Transformer Tappings:
1: 24 W – 417 ohm
2: 12 W – 833 ohm
3: 6 W – 1667 ohm
PRODUCT FEATURES:
Cut-out measurement: 200 mm (Ø)
Dimensions: 224 x 82 mm (Ø x D)
Weight: 1.45 kg
Construction: ABS
Front finish: TwistFix™Borderless finely perforated steel grill
Mounting: Quick-Fit™ mounting system
Colour: White (RAL9003)
Built-in depth: 78 mm
Dimensions: 224 mm (Ø)
