System specifications:
Speaker type: 3-way
Peak power handling: 1600 W
Program power handling: 800 W
Continuous power (AES): 400 W
Sensitivity (1W/1m): 94 dB
Sound Pressure (Max. W/1m): 121 dB
Frequency Response (± 3 dB): 62 Hz – 20 kHz
Frequency Range (-10 dB): 46 Hz – 20 kHz
Drivers: HF Compression driver with 1.4″ VC and 1″ throat; LF 1 x 8″ Coaxial LF with 2” voice coil, 1×8” LF with 1.8” voice coil
Impedance: 4 Ω (VEXO208), 8 Ω (VEXO208I)
Connectors: 2 x Speakon compatible (Linkthrough)
Dispersion: Avg 1 kHz – 4 kHz | -6 dB | 1/3 oct: Horizontal 96°, Vertical 100°
Product Features:
Dimensions: 710 x 260 x 290 mm (W x H x D)
Weight: 17 kg
Construction: 15 mm Multiply Plywood with multi-layer Polyurea coating
Finish: Cabinet finishing: Polyurethane coating
Front finish: Powder coated steel grill with acoustical foam
Mounting: Mounting pattern: 127 x 70 x M8 mount
Powerdrive mount: Powerdrive type 100 (127 x 70 mm)
Mounting & handling: Rigging points: 2 x M6 & 2 x M10
Accessories:
Included: Mounting bracket, Drop safety wire
Optional: 70V/100V transformer module
