Opis
Frequency Range: 65 Hz – 20 kHz Full space measurement using the music DSP preset and 150 Hz low pass.
Maximum SPL: 134 peak dB Maximum SPL is measured at 1 m using broadband pink noise at maximum output.
Power Consumption: 100 – 240 V~, 50 – 60 Hz, 1.6 – 0.8 A Current rating is 1/8 power.
Power Rating: 2000 W
Frequency Response: 85 Hz – 20 kHz Full space measurement using the music DSP preset and 150 Hz low pass.
Coverage (Nominal -6 dB) H: 90°
Coverage (Nominal -6 dB) V: 60°
LF Transducer: SMX2100 254 mm (10 in)
HF Transducer: DH3-B 1.25-in titanium compression driver
Crossover Frequency: 1700 Hz
Connector Type: (2) XLR/TRS combo jack and (1) XLR link output
Enclosure Material: 18-mm, 13-ply birch plywood with EVCoat
Grill: 16AWG steel with powdercoat
Suspension: (8) M10 suspension points
Height: 526 mm
Width: 330 mm
Depth: 365 mm
Weight Net: 20.3 kg
Shipping Weight: 22.9 kg
