Opis
Specifications:
Frequency range (-10 dB): 50 Hz – 20,000 Hz
Maximum SPL (continuous): 116 dB
Maximum SPL (peak): 122 dB
Sensitivity: 94 dB SPL 1 W, 1 m
Coverage angle conical: 75°
Power handling (continuous): 150 W
Power handling (peak): 600 W
Nominal impedance: 8 Ω
Recommended high pass: 50 Hz
Transformer taps 70 V line: 90 W; 45 W; 22,5 W; 11,3 W; 5,6 W
Transformer taps 100 V line: 90 W; 45 W; 22,5 W; 11,3 W
LF transducer size: 8 in
HF transducer size: 1 in
Material: Steel
Grille material: Powder coated steel
Connector type: 4-pin Euroblock Input + Pass through
Wire size: 12AWG (maximum)
Wire diameter: 3.3 mm2 (maximum)
Color: White; Customized colors
Color: RAL 9003 Signal white
Mounting cutout: 323 mm
Dimensions (Ø x D): 340 mm x 303 mm
Mounting depth: 292 mm
Ceiling thickness: 12,5 mm – 38 mm
Weight: 6 kg
Shipping weight: 13.5 kg
IP rating: IP34
Weatherization: Indoor
Operating temperature: 0 °C – 40 °C
