Electro Voice LRC-1060

EV_LRC-1060-2
EV_LRC-1060-2
lrc-1060-3
LRC_1060_4
LRC_1060_1

Column speaker, 0.6m, EN54

580 mm high
6x 2.5″ (63.5 mm) full-range drivers
2x 2.5″ (63.4 mm) passive radiators
20° symmetrical vertical coverage
130° horizontal coverage
75 Hz-15 kHz
122 dB SPL (peak)
Lo-Z, 8 ohms, 200W program
70/100V

MPC: Original price was: 675,00 €.Gotovina/Virman 590,00 Current price is: 590,00 €.

Kategorija:
Brand:

Isporučivo za 4-5 tjedana

Opis

Specifications:

Frequency range (-10 dB): 70 Hz – 15,000 Hz
Maximum sound pressure level at a distance of 1 m: 122 dB
Axial sensitivity: 90 dB SPL 1W/1m
Coverage angle HxV: 130° x 20°
Power handling (continuous): 100 W
Power handling (program): 200 W
Peak input voltage (Lo-Z): 80 V
Nominal impedance (Lo-Z): 8 Ω
Recommended high-pass: ≥70 Hz Butterworth, 24 dB/oct
Transformer taps 70 V line: 60 W; 30 W; 15 W; 8 W; 4 W
Transformer taps 100 V line: 60 W; 30 W; 15 W; 8 W
Transducer (quantity) size: 6x 2.5 in active drivers, 2x 2.5 in passive radiators
Connector type: 4-pin Euroblock, Input + Pass through
Wire size: 12 AWG (maximum)
Suspension points: 2x M8
Mounting: SwifTilt Multi-angle Tilt + Pan Bracket
Maximum horizontal pan angle: +/- 80° (at all down-tilt angles)
Vertical down-tilt angles: 0°, 2.5°, 5°, 7.5°, 10°, 15°, 20°, 25°
IP rating: FW (outdoor full exposure), IP55c
Color: RAL 9004 Signal black / RAL 9003 Signal white
Dimensions (H x W x D) 580 mm x 105 mm x 144 mm
Weight 4.4 kg
Shipping weight 6.5 kg
Included hardware: Tilt bracket, Pan bracket, Gland nut weather cover, Dual-ended Allen/TR20 key, M8x20 mm eyebolt (pre-installed)
