Technical Specifications:
Generation Element: Self-Biased condenser, back electret 2-micron thick, gold sputtered diaphragm
Frequency Response: 40 Hz to 20,000 Hz
Polar Pattern: Cardioid
Sensitivity, Open Circuit
Voltage, 1 kHz: 5.6mV/Pascal
Clipping Level (1% THD): >135 dB SPL
Equivalent Noise: <30 dB SPL “A” weighted (0 dB=20 micropascals) Dynamic Range: >105 dB
Signal to Noise (RE: 94 dB SPL): 64 dB
Output Impedance, 1 kHz: 250 ohms
Power Requirements: 24 to 52 Volt Phantom Power
Current Consumption: 6 mA typ. with P48 supply
Microphone Dimensions: Diameter = 0.412″ (10.5 mm)
Length = 1.263″ (32.1 mm), less strain relief
Inline Module Dimensions: Diameter = 0.875″ (22.2 mm)
Length = 5.350″ (135.9 mm)
Cable: 0.100″ (2.54 mm) diameter x 25 ft (7.6m) long
Polarity: Pin 2 positive, reference to pin3, with positive pressure on the diaphragm
Accessories Furnished: Mounting Hardware for inline module
Color: Nonreflecting black (H) or white (HW)
Environmental Conditions: Relative Humidity 0-50%: -29° to 74°C (-20° to 165°F)
Relative Humidity 0 to 95%: -29° to 57°C (-20° to 135°F)
Net Weight: 8.5 oz. (240 grams), with inline module
