Opis
Color: Black, white
Input Connections: 4-pin Phoenix
Nominal Impedance: 8 Ω
Speaker Type: Fullrange, Mid-High, Two-Way
Frequency Response (-3 dB): 60 – 20000 Hz
Frequency Response (-10 dB): 48 – 20000 Hz
Internal Crossover: Yes
Recommended High-Pass Frequency: 40 Hz
Sensitivity 1 W/1 m: 94 dB
Max. SPL/1m (calc): 123 dB
Coverage (Nominal -6 dB) H: 100°
Coverage (Nominal -6 dB) V: 100°
Rotatable Horn: Yes
System Power Handling (Continuous/Program/Peak): 200//800 Watts
LF Transducer: 8-inch EV8L
HF Transducer: 1.25-inch DH2005
Crossover Frequency : 1700 Hz
Minimum Impedance: 6 Ω
Enclosure Material: High Impact Polystyrene
Flying: Yes
Outdoor: Yes
Grill: Polyester Powder Coated, 18GA Galvanized Steel
Height: 451 mm
Width: 282 mm
Depth: 263 mm
Weight Net: 8.4 kg
