OMNITRONIC MPVZ-350.6

Opis

FEATURES:
6-zone PA mono mixing amplifier, 350 watts, adjustable zones
Comfortable control of PA speakers via 6-zone technology
6 PA zone outputs with separate 5-step level controls
Master PA output (70 V and 100 V)
Output for low-impedance speakers (4-16 ohms)
2 rear microphone inputs (6.3 mm jack, unbal.)
1 front microphone input (combination XLR/6.3 mm jack, unbal.) with adjustable priority circuit
All microphone inputs with separate level controls
3 line inputs (stereo RCA) with separate level controls
1 line output (stereo RCA)
Chime, switchable
Treble and bass control for the output signal
7-fold LED level display
Master control for the output signal
Fan-cooled
Protection circuits with LED indication: over current, short circuit, turn-on delay
Power connection: Fixed Power supply cord with safety plug (M)
Master equalizer: 1 x 2 band tone control Mono
Housing design: (19″) 48,3 cm rack installation 2 U

TECHNICAL SPECIFICATIONS:
Output power: 350 W RMS
Output type: 70 V, 100 V or 4-16 ohms
Output current: 5 A (70 V), 3.5 A (100 V)
Mic inputs: 5 mV, 600 ohms
Line inputs: 300 mV, 10 kohms
Speaker connectors: Screw connectors, terminal block
Distortion: 0.5 % (1 kHz)
S/N ratio: 85 dB (line), 75 dB (mic)
Power supply: 230 V AC, 50 Hz
Power consumption: 700,00 W
Frequency range: 80 – 16000 Hz
Power connection: Fixed Power supply cord with safety plug (M)
Impedance: 100 V ELA
Output power: 350 W RMS
Housing design: (19″) 48,3 cm rack installation 2 U
Width: 48,3 cm
Height: 8,9 cm
Depth: 38,5 cm
Weight: 14,1 kg
