Opis
FEATURES:
Built-in USB audio interface allows recordings and playback of digital audio files with a computer (PC and Mac)
Full duplex USB port: simultaneous recording and playback possible
2 mono input channels with gain control, 3-way EQ and pan control
4 stereo input channels with 3-way EQ and balance control
Adjustable stereo aux send output; aux return input
Tape input and output
Separate main mix and control room outputs
Adjustable headphones output
+48 V phantom power, can be switched centrally
Precise 4-digit stereo LED level display
Operation via supplied power unit
Rugged, compact metal housing
SPECIFICATIONS:
Power supply: 230 V AC, 50 Hz via supplied power unit
Inputs/sensitivity:
Mic, mono: 0.5 mV, XLR bal.
Line In, mono: 1 mV, 6.3 mm jack bal.
Line In, stereo: 10 mV,150 mV, RCA L/R
Aux Return: 100 mV, 6.3 mm jack L/R bal.
Tape In: 100 mV, RCA L/R
Outputs/level:
Main Out: 650 mV, 6.3 mm jack L/R unbal.
Control Room: 2 V. 6.3 mm jack L/R unbal.
Aux Send: 2 V, 6.3 mm jack unbal.
Tape Out: 2 V, RCA L/R
Headphones: 6 V max., 6.3 mm jack unbal.
USB port: 2.0, type B
Distortion: 0.05 %
S/N ratio: >74 dB
Frequency range: 20 – 20000 Hz
Tone control/channel:
Treble: ±15 dB at 12 kHz
Middle: ±15 dB at 2.5 kHz
Bass: ±15 dB at 80 Hz
Phantom power: +48 V
Dimensions (L x W x H): 260 x 189 x 72 mm
Power consumption: 27.00 W
Height: 7,2 cm
Depth: 26 cm
Width: 18,9 cm
Weight: 1,7 kg
