Opis
The stranding keeps the cable flexible and easy to handle while the copper clad aluminum construction results in an electrical performance between
copper and aluminum cables. It combines the advantages from two sides, such as solderability, lower weight and lower material cost than bare copper with the higher conductivity and higher strength than pure aluminum. The cable composition is made of 75% aluminum with 25% copper
Physical Characteristics:
Type of cable: 2-core loudspeaker cable
Inner conductor:
Material: CCA 49 x 0.25 mm (Ø)
Section: 2.5 mm²
Number of conductors: 2
Insulation material: PVC 3.8 mm (Ø)
Insulation colours: Red / Blue
Conductor compositions: 75 % Al – 25 % Cu
Separator: None
Outer jacket:
Material: Flexible PVC 9.8 mm (Ø)
Colours: Black
Inner conductor: American Wire Gauge 13 AWG
Standards and regulations:
RoHS2 compliant: According EU Directive 2011/65/EU
Reach compliant: According EC 1907/2006
Mechanical Characteristics:
Temperature range: Fixed installation: – 20 °C till + 80 °C; Mobile installation: – 15 °C till + 60 °C
Bending radius: Fixed installation 8 x outer diameter; Mobile installation: 10 x outer diameter
Electrical Characteristics:
Max. conductor: DC resistance 11 (Ω / km)
Dielectric strength: 2 (KV / 1 min. DC)
