RCF E-24

Opis

E 24 provides eighteen studio-quality 54 dB gain range Mic preamps with combo connectors. Two line inputs are switchable to Hi-Z input. The input section also features three stereo line inputs and a stereo return. Input channels from 1 to 8 are equipped with a single-control compressor. The eighteen mono channels are provided with 4-band EQs, including shelving high and low bands and 2 semi-parametric mid-bands (mid-high and mid-low) with frequency selection and switchable Q choice, wide or narrow. The stereo input channels are provided with a three band EQ.

18 Mic/line IN, 3 stereo line IN
1 Stereo return input
8 Single-control dynamic compressors (ch.1 – ch.8)
4 Band semiparametric EQ
3 Band EQ on stereo inputs
6 Aux sends per channel
100 mm progressive faders with dust cover
2 Stereo groups
32-Bit floating-point Z.CORE DSP effects section
