Opis
ES 3323 II is a mixer-amplifier with 4 mic-line audio inputs on removable connectors (the first input also has an XLR socket), CD/USB/Bluetooth – MP3 player and tuner and an aux input for an additional external music source. The amplifier nominal power is 320 W, available on 100 – 70 V constant voltage output (for loudspeakers having 100 – 70 V transformers). The 3 PAGING buttons on the front panel can be used to select zones to be paged by either the channel 1 or 4; The 3 MUSIC buttons turn the music on in the respective zones. As (optional) system expansion, it is possible to link a second generic external amplifier (delivering enough power for all loudspeakers, i.e. RCF UP 2321) to keep the background music in the zones that are not paged
FEATURES:
• CD-USB/MP3 Player / FM tuner / Mixer Amplifier / 3 zone control – Bluetooth connection with external
devices
• IR Remote control for CD – USB/MP3 player & tuner functions
• Full digital technology amplifier 320W RMS, 100V-70V outputs
• 4 universal inputs with phantom facility, Presence Control and per-channel High-Pass filters
• RJ45 connectors on input 2 and 3 for connection to BM3001 and BM 3003 microphone
• Screw terminal connections, additional XLR and RJ45 input connections available
• Configurable Priority settings, VOX facility on input 1
• Selectable aux input for music source with volume and tone controls
• USB port on front panel allows reproduction of MP3 files from a memory stick
• Music On Hold and PRE outputs
