Power System Type: Bi-Amp. with DSP processor
Total Output Power: 284W RMS @8Ω; 453W RMS @4Ω
Low Output Power: 232W RMS @8Ω Class H; 364W RMS @4Ω Class H
High Output Power: 52W RMS @4Ω Class AB; 89W RMS @4Ω Class AB
Maximum SPL @ 1m: 124dB SPL
Frequency Response: 50Hz/20kHz -10dB
Impedance Low-High: Low 4Ω-High 8Ω
Crossover Frequency: 2000Hz-DSP processor
Protection Low-High : DSP Lim./Comp. each section
Digial Presets: LIVE-SUBWOOFER-STUDIO
Lower Frequency: 15″/385mm-3″ voice coil
High Frequency: 1″ compression driver, 1.75″ voice coil
Horn Coverage (H×V): 90° H × 45° V
Input Impedance : 30kΩ Balanced/15kΩ Unbalanced
Connectors : Input with Jack/Link with XLR
Plastic Reinforced Cabinet : Trapezoidal & Monitor shape
Hardware Suspension: Six suspension points
Amplifier Protections: Soft Start-Short Circuit-DC voltage-Thermal Protection
External Control: Mic/Line Volume-Preset switch-LED Clip-Ground switch
Power Supply: 230Volt/115Volt-50/60Hz
Dimensions (H×W×D): 660 × 396 × 415 mm
Weight: 29.3 kg
