Opis
SPECIFICATIONS:
Frequency Range (-10 dB): 65 – 20000kHz (Half Space)
Suspension: Six M8 threaded points
Weatherized: No
Minimum Impedance: 6Ω
Nominal Impedance: 8Ω
HF Transducer: One 1.3-inch (33 mm) diaphragm ICT-1-8 compression driver
LF Transducer: One 8-inch (203 mm) ICT-8-8 woofer
Speaker Type: Full-Range, Two-Way
Frequency Response (-3 dB): 110 – 16000Hz (Half Space)
Axial Sensitivity (SPL, 1 W @ 1 m): 95dB ((1W/1m))
Max. SPL/1m (calc): 123dB
Coverage (Nominal -6 dB) H: 90°
Coverage (Nominal -6 dB) V: 50°
Power Rating: 700W
Passive Power Handling: 700W peak
System Power Handling (Continuous/Program/Peak): 175//700Watts (EIA RS-426A (eight hours))
Recommended High-Pass Frequency: 90Hz
Connector Type: 4-pin Phoenix/Euroblock screw terminals (up to 10 AWG wire)
Enclosure Material: 9-ply hardwood plywood
Grille: 18-gauge steel with cloth behind
Available Color: Black or white
Height: 247 mm
Width: 409 mm
Depth: 237 mm
Weight Net: 7.4 kg
Shipping Weight: 10.3 kg
Finish: Textured paint
Waveguide: 6 in. x 6 in., rotatable
