XCS312s are designed to be used with a ratio of four XLD281 or XLD291 full-range systems for each XCS312 subwoofer. The XLVC family consists of two full-range Line Array Elements with dual woofers, two full-range Line Array Elements with single woofers and two subwoofer systems. The dual woofer Line Array Element includes the XLD281 with a 120 degree horizontal coverage pattern and the XLD291 with a 90 degree horizontal coverage pattern. The single-woofer Line Array Element includes the XLE181 with a 120 degree horizontal coverage pattern and the XLE191 with a 90 degree horizontal coverage pattern.
The XCS312 cardioid subwoofer module has the same rigging footprint as the XLD281 and XLD291, which allows it to be directly arrayed above, or below XLD281 or XLD291 full-range systems. LAPS modeling software quickly provides array configurations and rigging information. XCS312 subwoofers can be used as the base for ground-stack applications, or by using EV’s XGS-4 ground-stack Kit for XLVC. XLVC delivers unprecedented performance in applications ranging from live reinforcement, to performing arts venues, to house-of-worship.
Low Frequency Power Handling (continuous/program/peak): 1000/2000/4000 Watts
